Aurelia sortable

Installation

JSPM

jspm install npm:oribella-aurelia-sortable

NPM

npm install oribella-aurelia-sortable

Load the plugin

export function configure(aurelia) {
  aurelia.use
    .standardConfiguration()
    .developmentLogging()
    .plugin("oribella-aurelia-sortable");

  aurelia.start().then(a => a.setRoot());
}

Use the plugin

sortable, sortable-item will be available as global custom attributes.

To get started you need to bind the sortable, sortable-item attributes in conjunction with the repeat attribute.

<ul oa-sortable="items.bind: items">
  <li repeat.for="item of items" oa-sortable-item="item.bind: item"></li>
</ul>

This will enable the plugin to keep track of and move around the items.

scroll

If the sortable custom attribute is in an area that is scrollable you have to bind either a selector or an Element or document:

<!-- Other bindings omitted -->
<div oa-sortable="scroll.bind: '.page-host'">
</div>

Default scroll='document'

scrollSpeed scrollSensitivity

so it can auto scroll when needed. If you want you may even do a manual scroll when it's auto scrolling or combine them by first auto scrolling then manual scrolling and it should still behave as intended. If you are not happy with the sensitivity or scroll speed for the auto scroll you can set it with below bindings:

<!-- Other bindings omitted -->
<div oa-sortable="scroll-sensitivity.bind: 20; scroll-speed.bind: 20">
</div>

Default scrollSpeed=10 - how many pixels it will scroll for each frame

Default scrollSensitivity=10 - how many pixels from the scroll bounding threshold until it starts auto scrolling.

axis

If you have a vertical or horizontal list you can lock the sortable axis movement with:

<!-- Other bindings omitted -->
<!-- Lock to horizontal movement -->
<div oa-sortable="axis: 'x'">
</div>
<!-- Lock to vertical movement -->
<div oa-sortable="axis: 'y'">
</div>

Default axis=3 - sets the allowed axis movement. Which is both horizontal and vertical movement.

dragZIndex

To make sure that the dragging of a sortable item always is on top of other elements make sure to bind:

<!-- Other bindings omitted -->
<div oa-sortable="drag-z-index.bind: 120">
</div>

Default dragZIndex=1 - z-index of the dragging sortable item.

disallowedDragTagNames

To be able to have a sortable where you might be editing the sortable items you can control this by:

<!-- Other bindings omitted -->
<div oa-sortable="disallowed-drag-selectors.bind: 'DIV'">
</div>

Default disallowedDragTagNames=['INPUT', 'SELECT', 'TEXTAREA'] - element tags that disallows start dragging.

allowedDragSelector allowedDragSelectors

<!-- Other bindings omitted -->
<div oa-sortable="allowed-drag-selector.bind: '.handle'">
</div>

or

<!-- Other bindings omitted -->
<div oa-sortable="allowed-drag-selectors.bind: ['.handle1', '.handle2]">
</div>

allowDrag

If that is insufficient:

<!-- Other bindings omitted -->
<div oa-sortable="allow-drag.call: allowDrag($event);">
</div>

Default allowDrag

@bindable public allowDrag = ({ event }: { event: Event, item: SortableItem }) => {
  const target = (event.target as HTMLElement);
  if (this.allowedDragSelector &&
    !matchesSelector(target, this.allowedDragSelector)) {
    return false;
  }
  if (this.allowedDragSelectors.length &&
    this.allowedDragSelectors.filter((selector) => matchesSelector(target, selector)).length === 0) {
    return false;
  }
  if (this.disallowedDragSelectors.filter((selector) => matchesSelector(target, selector)).length !== 0) {
    return false;
  }
  if (target.isContentEditable) {
    return false;
  }
  return true;
}

where $event has event and item properties.

event - the native DOM event

item - the sortable-item view-model

onStop

<!-- Other bindings omitted -->
<div oa-sortable="on-stop.call: onStop()">
</div>

typeFlag

<!-- Other bindings omitted -->
<div oa-sortable-item="type-flag.bind: 1">
</div>

You can use an abstract bit type flag to enable/disable moving between lists. This is useful for more advanced scenarios i.e multi nested sortables. Checkout the advanced demo for more insight. It will evaluate

fromTypeFlag & toTypeFlag

If you want 4 exclusive types you can use for example

1

2

4

8
